Traction 2025

Technical specification

Size	15" (27.5") / 17", 19", 21" (29")
Frame	double butted hydroformed alloy 6061 27.5" / 29"
Front fork	RST Aerial 27.5 / 29 TRL, air, remote lock out (100 mm)
Head parts	PRESTINE Integrated, 1.5" tapered
Chain Wheel	SHIMANO M510-1, 34 teeth, 170 / 175 mm cranks
BBParts	SHIMANO BB-52 BB, unit
Rear derailleur	SHIMANO Deore
Shifters	SHIMANO Deore (12)
Free wheel	SHIMANO CS-M6100-12, 10-51 (12)
Chain	KMC X12
Hubs	QUANDO Disc / SHIMANO, 32 holes
Brakes	SHIMANO BR-MT410, disc hydraulic (7" rotors)

Brakes levers	SHIMANO BL MT401
Rims	AUTHOR Xenon TRC 27.5/29, 32 holes
Spokes	black stainless steel 2.0 mm
Tires	VITTORIA Barzo, aramid, 27.5"/29" × 2.25"
Pedals	AUTHOR alloy
Handlebar	AUTHOR Flatbar, 9°, 700 / 720 mm
Stem	AUTHOR alloy
Seat post	AUTHOR alloy (31.6)
Seat clamp	AUTHOR (34.9)
Saddle	AUTHOR Navigator
Speed	12

Geometry and sizes

Size	27,5"/15"	29"/17"	29"/19"	29"/21"
Min. figure ~~[cm]~~	152	168	178	188
Max. figure ~~[cm]~~	168	179	189	202
S/T c-t ~~[mm]~~	381	432	483	535
S/T c-c ~~[mm]~~	0	0	0	0
T/T h ~~[mm]~~	570	605	630	650
T/T a ~~[mm]~~	555	592	611	628
H/T ~~[mm]~~	90	100	115	130
C/S ~~[mm]~~	435	445	445	445
W/B ~~[mm]~~	1082	1135	1161	1182
S/T ang. ~~[°]~~	73	74	74	74
H/T ang. ~~[°]~~	69	69	69	69
F/L ~~[mm]~~	495	510	510	510
B/B drop ~~[mm]~~	35	65	65	65
B/B width ~~[mm]~~	73	73	73	73
Reach ~~[mm]~~	397	428	449	465
Stack ~~[mm]~~	566	616	630	644
F/R ~~[mm]~~	44	51	51	51
Handlebars ~~[mm]~~	0	0	0	0
Stem ~~[mm]~~	0	0	0	0
Cranks ~~[mm]~~	0	0	0	0

maxmin

~~202 cm~~

~~Choose the height of the character by moving the pointer on the scale.~~

The recommended size and stature are just indicative. It is recommended to always consult your choice with the dealer.

S/T c-t - seat tube (center-top), length of the seat tube from the middle of BB parts to its peak
S/T c-c - seat tube (center-center), length of the seat tube from the middle of BB parts to an axle of the upper tube
T/T h - top tube horizontal, horizontal lenght of the upper tube
T/T a - top tube actual, real lenght of the upper tube
H/T - head tube, head tube lenght
C/S - chain stay, chain brace lenght
W/B - wheel base, wheelbase (front and rear axle lenght)
S/T ang. - seat tube angel, angle between the seat tube axis and an imaginary line connecting the axes of the front and rear wheel
H/T ang. - head tube angel, angle between the head tube axis and an imaginary line connecting axes of the front and rear wheels
F/L - fork length, fork length from the head parts bottom to the middle of the front wheel
B/B drop - bottom bracked drop, lenght between an imaginary line connecting wheels centers and BB parts, measured from BB parts
F/R - fork rake, distances between the head tube axis and fork axis measured at center of the front wheel, so-called. off set
