Size | 17", 19" |
---|---|
Frame | alloy 6061 700c (L) |
Front fork | RST Neon ML lock out (60 mm) |
Head parts | FSA Integrated 1-1/8" |
Chain Wheel | SUNTOUR NEX-T102 42-34-24 teeth 170 mm cranks |
BBParts | SUNTOUR XCM cartridge |
Front derailleur | SHIMANO TX50 (34.9) |
Rear derailleur | SHIMANO Acera |
Shifters | SHIMANO Acera (24) |
Free wheel | SHIMANO HG-31-8 11-32 (8) |
Chain | KMC Z72 |
Hubs | QUANDO 32 holes |
Brakes | TEKTRO 855AL |
Brakes levers | SHIMANO Acera |
Rims | AUTHOR Xenon Cross black 32 holes |
---|---|
Spokes | steel |
Tires | AUTHOR Tour 700 x 38c |
Pedals | AUTHOR Nonslip resin |
Handlebar | KALIN steel 20 mm 620 mm |
Grips | AUTHOR high density foam |
Stem | ZOOM adjustable |
Seat post | ZOOM alloy (31.6) |
Seat clamp | AUTHOR (34.9) |
Saddle | AUTHOR Soft Touch |
Speed | 24 |
Weight | 13,2 Kg / 19" |
Size | 17" | 19" |
---|---|---|
Min. figure | 155 | 167 |
Max. figure | 169 | 182 |
S/T c-t | 432 | 483 |
S/T c-c | 0 | 0 |
T/T h | 553 | 558 |
T/T a | 572 | 579 |
H/T | 120 | 130 |
C/S | 440 | 440 |
W/B | 1044 | 1050 |
S/T ang. | 73 | 73 |
H/T ang. | 71 | 71 |
F/L | 470 | 470 |
B/B drop | 45 | 45 |
B/B width | 0 | 0 |
Reach | 0 | 0 |
Stack | 0 | 0 |
F/R | 43 | 43 |
Handlebars | 0 | 0 |
Stem | 0 | 0 |
Cranks | 0 | 0 |
The recommended size and stature are just indicative. It is recommended to always consult your choice with the dealer.
