AUTHOR Compact ASL 2023-24
AUTHOR Compact ASL 2023-24
AUTHOR Compact ASL 2023-24AUTHOR Compact ASL 2023-24
  » Bicycles » ladies » cross 700c
  » Bicycles » cross » cross 700c

Compact ASL 2023-24Archivní model 2025

Colour variants
Alloy ASL frameSuspension fork RST Neon TComponents SHIMANO TourneyComfort grip AUTHOR (reinforced foam)Tires AUTHOR Cross 700 × 38cBrake V-TEKTROComfort saddle AUTHOR Area
Buy nowspecial price 6 990 Kč
original price  12 990 Kč
Add to compareadditional accessories
other models
Vertigo15 990Vertigo ASL15 990Horizon ASL14 590Linea14 590Thema13 590
Interested in other model`s year?

Technical specification

Size15", 17", 19"
Framealloy 6061 (ASL)
Front forkRST Neon T (60 mm)
Head partsVP COMP 1-1/8"
Chain WheelPROWHEEL, 42-34-24 teeth, 170 mm cranks
BBPartsVP COMP, cartridge
Front derailleurSHIMANO TY510 (31.8)
Rear derailleurSHIMANO TY500
ShiftersSHIMANO (21)
Free wheelSHIMANO MF-TZ510-7, 14-28 (7)
ChainKMC Z7
HubsQUANDO, 36 holes
BrakesTEKTRO V
Brakes leversSHIMANO
Rimsalloy, 36 holes
Spokessteel
TiresAUTHOR Cross 700 × 38c
Pedalsplastic
Handlebarsteel, 20 mm, 660 mm
GripsAUTHOR high density foam
StemZOOM alloy
Seat postZOOM alloy (27.2)
Seat clampAUTHOR (31.8)
SaddleAUTHOR Area
Speed21
Weight12,5 kg / 17"

Geometry and sizes

Size 15" 17" 19"
Min. figure [cm] 145 155 170
Max. figure [cm] 158 172 185
S/T c-t [mm] 381 432 483
S/T c-c [mm] 0 0 0
T/T h [mm] 550 570 590
T/T a [mm] 545 554 568
H/T [mm] 130 140 150
C/S [mm] 440 440 440
W/B [mm] 1054 1075 1095
S/T ang. [°] 73.5 73.5 73.5
H/T ang. [°] 70.5 70.5 70.5
F/L [mm] 470 470 470
B/B drop [mm] 60 60 60
B/B width [mm] 68 68 68
Reach [mm] 0 0 0
Stack [mm] 0 0 0
F/R [mm] 51 51 51
Handlebars [mm] 0 0 0
Stem [mm] 0 0 0
Cranks [mm] 0 0 0
maxmin
silueta
Choose the height of the character by moving the pointer on the scale.
Compact ASL 2023-24

The recommended size and stature are just indicative. It is recommended to always consult your choice with the dealer.

  • S/T c-t - seat tube (center-top), length of the seat tube from the middle of BB parts to its peak
  • S/T c-c - seat tube (center-center), length of the seat tube from the middle of BB parts to an axle of the upper tube
  • T/T h - top tube horizontal, horizontal lenght of the upper tube
  • T/T a - top tube actual, real lenght of the upper tube
  • H/T - head tube, head tube lenght
  • C/S - chain stay, chain brace lenght
  • W/B - wheel base, wheelbase (front and rear axle lenght)
  • S/T ang. - seat tube angel, angle between the seat tube axis and an imaginary line connecting the axes of the front and rear wheel
  • H/T ang. - head tube angel, angle between the head tube axis and an imaginary line connecting axes of the front and rear wheels
  • F/L - fork length, fork length from the head parts bottom to the middle of the front wheel
  • B/B drop - bottom bracked drop, lenght between an imaginary line connecting wheels centers and BB parts, measured from BB parts
  • F/R - fork rake, distances between the head tube axis and fork axis measured at center of the front wheel, so-called. off set

Availability

Colour variantSizeIn storesPurchaseCityContacts on sellerModel code
17"2 stores4294780225
 ▪   SPORT CYKLO s.r.o.in stockbuy nowHolešov603 373 886, sportcyklo@gmail.commap
 ▪   ValmezBikein stockbuy nowValašské Meziříčí734 393 565, prodejna@valmezbike.czmap
⟲  In other storesin 2 daysdealers
19"10 stores4294780325
 ▪   SPORT CYKLO s.r.o.in stockbuy nowHolešov603 373 886, sportcyklo@gmail.commap
 ▪   Cyklotech Jana Hlaváčováin stockbuy nowKarviná - Mizerov774 544 311, info@cyklotech.czmap
 ▪   Dům sportu Stratílek, s.r.o.in stockbuy nowLitomyšl606 613 399, cyklo@stratilek.czmap
 ▪   AXIT bike sportin stockbuy nowNáchod491 426 020, axit@axit.czmap
 ▪   OtroKolo, s.r.o.in stockbuy nowOtrokovice775575822, info@otrokolo.czmap
 ▪   CykloCentrum Praha Holešovicein stockbuy nowPraha 7725 085 309, holesovice@cyklocentrum.czmap
 ▪   Jízdní kola Rezek - Rezkováin stockbuy nowRakovník313 517 417, jizdnikola.rezek@tiscali.czmap
 ▪   Pavel Brabecin stockbuy nowRumburk602 112 875, brabec.pavel@gmail.commap
 ▪   eM Sport Martin Matoušekin stockbuy nowSlaný775 710 011, info@kolaslany.czmap
 ▪   CSM Cyklo Sport Mikšíkin stockbuy nowVrchlabí604 628 498, csm@centrum.czmap
⟲  In other storesin 2 daysdealers
15"2 stores4294781125
 ▪   Dům sportu Stratílek, s.r.o.in stockbuy nowLitomyšl606 613 399, cyklo@stratilek.czmap
 ▪   eM Sport Martin Matoušekin stockbuy nowSlaný775 710 011, info@kolaslany.czmap
⟲  In other storesin 2 daysdealers
17"3 stores4294781225
 ▪   Cyklo sport Stratílekin stockbuy nowHradec Králové601 379 902, cyklohk@stratilek.czmap
 ▪   Dům sportu Stratílek, s.r.o.in stockbuy nowLitomyšl606 613 399, cyklo@stratilek.czmap
 ▪   CSM Cyklo Sport Mikšíkin stockbuy nowVrchlabí604 628 498, csm@centrum.czmap
⟲  In other storesin 2 daysdealers
19"2 stores4294781325
 ▪   Dům sportu Stratílek, s.r.o.in stockbuy nowLitomyšl606 613 399, cyklo@stratilek.czmap
 ▪   eM Sport Martin Matoušekin stockbuy nowSlaný775 710 011, info@kolaslany.czmap
⟲  In other storesin 2 daysdealers
Poznámka: Stav dostupnosti kola se aktualizuje 1× denně v ranních hodinách.

Product options

silver / green17" = UA#4294780225   19" = UA#4294780325
grey-matt / pink15" = UA#4294781125   17" = UA#4294781225   19" = UA#4294781325

additional accessories

AUTHOR Frame bag A-R244
foto 1
foto 2
side
1/4
350 KčR244The Author saddle bag A-R244 is the universal bag with the one main compartment and one flat pocket. ... more »
AUTHOR Frame bag A-R281 F GSB
425 KčR281 F GSBFrame bag, universal velcro attachment for fixation in front frame triangle (on most of types of fra ... more »
AUTHOR Stand AKS-06S C 22"-29" (černá)
AUTHOR Stand AKS-06S C 22"-29" (černá)
1/2
115 Kč 175 Kč AKS-06S CKick Stand Author for direct frame fixation. Adjustable for size 14"- 29", Material AL6061-T6 / ... more »
AUTHOR Stand AKS-09A
325 Kč 450 Kč AKS-09A CKick Stand Author for direct frame fixation. Adjustable for size 24"- 29", Material AL6061-T6. ... more »
AUTHOR Stand AKS-530 RS
foto 1
1/2
399 KčAKS-530 RSAlloy kick stand designed for direct rear fork down tube fixation (tube profile 22 - 32 mm), recomen ... more »
Carrier ACR-16-Alloy
foto 3
dimensions
1/3
695 KčACR-16-Alloy566 g • top place 360 x 105 mm • A tough rear rack AUTHOR ACR-16-Alu. Equipped with adjustable legs to fit most 24” to 29” wheel ... more »
AUTHOR Carrier ACR-20N-Alu
750 KčACR-20N-Alu680 g • top place 380x135 • Carrier Author Expedition for extreme load and conditions, made from AL6061 tubes d.10mm - light wei ... more »
