AUTHOR A-Ray 29 2019Archivní model 2019

Colour variants
2
Double butted alloy frameROCK SHOX Recon Gold RL forkShocker ROCK SHOX Monarch RL HVI
special price 51 990 Kč
original price  69 990 Kč SOLD OUT
other models
Interested in other model`s year?

Technical specification

Size17.5", 19", 21"
Framedouble butted alloy 6061 29"
ShockerROCK SHOX Monarch RL HVI 184 / 44 mm (rear travel 100 mm)
Front forkROCK SHOX Recon Gold RL Remote 29 15 Solo Air air, lock out 15 mm thru axle 1.5" tapered steerer (100 mm)
Head partsPRESTINE Integrated 1.5" tapered
Chain WheelSHIMANO SLX-B2 (Boost) 36-26 teeth 170 / 175 mm cranks
BBPartsSHIMANO BB-MT800 PF type
Front derailleurSHIMANO SLX
Rear derailleurSHIMANO XT
ShiftersSHIMANO SLX (22)
Free wheelSHIMANO M7000-11 11-42 (11)
ChainSHIMANO HG601
HubsMAVIC XA 29 wheel set 24 holes boost 15 x 110 mm thru front axle boost 12 x 148 mm thru rear axle
BrakesSHIMANO Deore disc hydraulic (7" rotors)
Brakes leversSHIMANO Deore
SpokesMAVIC
TiresVITTORIA Barzo kevlar 29" x 2.25"
HandlebarRITCHEY MTN Comp 2x9D 9° 700 mm
GripsAUTHOR Pro Lock
StemRITCHEY Comp 4-Axis
Seat postRITCHEY Comp (31.6)
Seat clampAUTHOR (34.9)
SaddlePROLOGO Nago Evo X10
Speed22
Weight13,6kg / M"

Geometry and sizes

Size 17,5" 19" 21"
Min. figure [cm] 171 179 188
Max. figure [cm] 181 189 202
S/T c-t [mm] 445 483 533
S/T c-c [mm] 0 0 0
T/T h [mm] 580 600 630
T/T a [mm] 550 568 594
H/T [mm] 105 115 125
C/S [mm] 440 440 440
W/B [mm] 1123 1141 1171
S/T ang. [°] 74.7 74.3 74.3
H/T ang. [°] 68.5 68.5 68.5
F/L [mm] 501 501 501
B/B drop [mm] 46 46 46
B/B width [mm] 92 92 92
Reach [mm] 418 433 459
Stack [mm] 593 602 611
F/R [mm] 51 51 51
Handlebars [mm] 700 700 700
Stem [mm] 90 100 110
Cranks [mm] 170 175 175
maxmin
silueta
Choose the height of the character by moving the pointer on the scale.
AUTHOR A-Ray 29 2019

The recommended size and stature are just indicative. It is recommended to always consult your choice with the dealer.

  • S/T c-t - seat tube (center-top), length of the seat tube from the middle of BB parts to its peak
  • S/T c-c - seat tube (center-center), length of the seat tube from the middle of BB parts to an axle of the upper tube
  • T/T h - top tube horizontal, horizontal lenght of the upper tube
  • T/T a - top tube actual, real lenght of the upper tube
  • H/T - head tube, head tube lenght
  • C/S - chain stay, chain brace lenght
  • W/B - wheel base, wheelbase (front and rear axle lenght)
  • S/T ang. - seat tube angel, angle between the seat tube axis and an imaginary line connecting the axes of the front and rear wheel
  • H/T ang. - head tube angel, angle between the head tube axis and an imaginary line connecting axes of the front and rear wheels
  • F/L - fork length, fork length from the head parts bottom to the middle of the front wheel
  • B/B drop - bottom bracked drop, lenght between an imaginary line connecting wheels centers and BB parts, measured from BB parts
  • F/R - fork rake, distances between the head tube axis and fork axis measured at center of the front wheel, so-called. off set

Product options

black-matt / red17,5" = UA#42913302   19" = UA#42913303   21" = UA#42913304
