You can add bike models to compare on each product card by pressing Add to compare. You can compare a maximum of 4 bike models.
| Image |  |  |  |  |
|---|---|---|---|---|
| Product | AUTHOR Vision 29 2016 | AUTHOR REVOLT 2008 | AUTHOR A-Ray 5.0 2013 | AUTHOR Vision 29 2018 |
| Code | UA#42864402 | UA#42743900 | UA#42816202 | UA#42894702 |
| Model card | link | link | link | link |
| Size | 17", 19", 21" | 16.5", 17.5", 19", 20", 21" | 17", 19", 21" | 17', 19', 21' |
| Frame | triple butted hydroformed alloy 6061 29" | EASTON Ultralite alloy 26" | AUTHOR A carbon monocoque, suspension oil-air shocker FOX Float RPL lock out, 165 / 38 mm (rear travel 100 mm) | triple butted hydroformed alloy 6061 29' |
| Front fork | ROCK SHOX Recon Gold TK 29 15 Solo Air air, remote lock out 15 mm thru axle 1.5" tapered steerer (100 mm) | ROCK SHOX Recon SL Solo Air air, lock out (100 mm) | FOX 32 Float 100 Fit RL air, lock out 15 mm thru axle 1.5" tapered steerer (100 mm) | ROCK SHOX Recon Gold RL Remote 29 15 Solo Air air, remote lock out 15 mm thru axle 1.5' tapered steerer (100 mm) |
| Head parts | AUTHOR Integrated 1.5" tapered | RITCHEY Zero Logic Integ Comp 1-1/8" | FSA Orbit 1.5B 1.5" tapered | FSA Orbit 1.5B 1.5' tapered |
| Chain Wheel | SHIMANO Deore 38-24 teeth 170 / 175 mm cranks | FSA V-Drive MegaExo 44-32-22 170 / 175 mm cranks | SHIMANO XT-10 42-32-24 teeth 170 / 175 mm cranks | SHIMANO SLX 38-28 teeth 170 / 175 mm cranks |
| BBParts | SHIMANO BB52 BB unit | FSA MegaExo BB unit | SHIMANO XT-10 BB unit | SHIMANO BB-MT800 BB unit |
| Front derailleur | SHIMANO Deore (34.9) | SRAM X7 (34.9) | SHIMANO XT (34.9) | SHIMANO SLX (34.9) |
| Rear derailleur | SHIMANO XT "clutch" | SRAM X7 | SHIMANO XT | SHIMANO SLX |
| Shifters | SHIMANO SLX (20) | SRAM X7 Triggers (27) | SHIMANO XT (30) | SHIMANO SLX (22) |
| Free wheel | SHIMANO HG50-10 11-36 (10) | SRAM PG-950 11-34 | SHIMANO M771-10 11-36 (10) | SHIMANO M7000-11 11-42 (11) |
| Chain | SHIMANO HG54 | SRAM PC-951 | SHIMANO HG-74 | SHIMANO HG601 |
| Hubs | AUTHOR Helium 15 / Xenon 15 x 100mm thru axle 32 holes | AUTHOR cartridge 32 holes | SHIMANO XT Disc 15 mm thru axle 32 holes | AUTHOR Helium 15 / Xenon 15 x 100mm thru axle 32 holes |
| Brakes | SHIMANO Deore disc hydraulic (7" rotors) | SHIMANO LX | SHIMANO XT disc hydraulic (6" rotors) | SHIMANO Deore disc hydraulic (7' rotors) |
| Brakes levers | SHIMANO Deore | AVID FR5 | SHIMANO XT | SHIMANO Deore |
| Rims | AUTHOR Krypton Pro 29 32 holes | AUTHOR Xenon Pro 32 holes | AUTHOR Helium Pro 32 holes | AUTHOR Krypton 29 32 holes |
| Spokes | black stainless steel 2.0 mm | SANDVIK black stainless steel 1, 8 mm | black stainless steel 2.0 mm triple butted | black stainless steel 2.0 mm |
| Tires | VITTORIA Barzo kevlar 29" x 2.10" | AUTHOR PANARACER Beetle Juice 26" x 2.00" | GEAX Barro Race Kevlar 26" x 2.00" | VITTORIA Barzo kevlar 29' x 2.25' |
| Pedals | SHIMANO M520 clipless | SHIMANO M520 clipless | SHIMANO M540 clipless | - |
| Handlebar | AUTHOR Flatbar 0 mm 700 mm | EASTON EA30 31.8 mm | EASTON EC90 carbon 20 mm 635 mm | RITCHEY Comp Flat 10° 660 / 700 mm |
| Grips | AUTHOR Pro Lock | AUTHOR superlite foam | AUTHOR GripLock | AUTHOR Pro Lock |
| Stem | AUTHOR alloy | EASTON EA50 31.8 mm | EASTON EA90 | RITCHEY Comp 4-Axis |
| Seat post | AUTHOR alloy (31.6) | EASTON EA50 (31.6) | EASTON EC70 Zero carbon (31.6) | RITCHEY Comp (31.6) |
| Seat clamp | AUTHOR (34.9) | AUTHOR (34.9) | AUTHOR (34.9) | AUTHOR (34.9) |
| Saddle | AUTHOR Summit | FIZIK Nisene Sport | FIZIK Tundra II k:ium | PROLOGO Nago Evo X10 |
| Speed | 20 | 27 | 30 | 22 |
| Weight | 12.9 kg / 19" | 11.80kg/ 19" | 11,1 Kg / 19" | 12,1 kg / 19' |
