AUTHOR Elevation ASL 2025

Colour variants
New motor SHIMANO STEPS EP6 – 85 NmHigh capacity battery SHIMANO EN806 – 630 WhNew SHIMANO e-group CUES for e-bikesNew synoptic display EN610Air fork RST FIRST 110-15, travel 120mmE-LINKGLIDE cassette 11-50/11 speedErgonomic saddle E-Donna
other models

Technical specification

Size17", 19"
Framedouble butted hydroformed alloy 6061 27.5" (integrated battery)
Front forkRST F1RST 110-15 Air, air, lock out, 15 mm thru axle boost, 1.5" tapered steerer (120 mm)
EngineSHIMANO Steps EP-600, 250 W
BatterySHIMANO E-806 Li-Ion, 36 V, 17,5 Ah, 630 Wh
DisplaySHIMANO Steps E-610, LCD
Head partsPRESTINE Integrated 1.5" tapered
Chain WheelSHIMANO Steps EN-600, 38 teeth, 170 / 175 mm cranks
BBPartsSHIMANO Steps
Rear derailleurSHIMANO Cues 6000
ShiftersSHIMANO Cues 6000 (11)
Free wheelSHIMANO CS-LG400-11, 11-50 (11)
ChainKMC eGlide
HubsQUANDO, 15 × 110 mm thru front axle 12 × 148 mm thru rear axle 32 holes
BrakesTRP Slate EVO, 4-piston disc hydraulic (7" rotors)
Brakes leversTRP Slate EVO
RimsAUTHOR E-Krypton 27.5, 32 holes
Spokesblack stainless steel 2.2 mm
TiresVITTORIA Barzo G2.0 aramid 27.5" × 2.25"
PedalsHT platform
HandlebarAUTHOR, 15 mm, 700 / 720 mm
GripsAUTHOR high density foam
StemAUTHOR alloy
Seat postAUTHOR alloy (30.9)
Seat clampAUTHOR (34.9)
SaddleAUTHOR E-Donna
Speed11

Geometry and sizes

Size 17" 19"
Min. figure [cm] 158 169
Max. figure [cm] 172 184
S/T c-t [mm] 432 483
S/T c-c [mm] 0 0
T/T h [mm] 600 620
T/T a [mm] 584 597
H/T [mm] 120 130
C/S [mm] 460 460
W/B [mm] 1155 1176
S/T ang. [°] 73 73
H/T ang. [°] 68 68
F/L [mm] 540 540
B/B drop [mm] 51 51
B/B width [mm] 0 0
Reach [mm] 402 419
Stack [mm] 647 656
F/R [mm] 43 43
Handlebars [mm] 0 0
Stem [mm] 0 0
Cranks [mm] 0 0
maxmin
silueta
Choose the height of the character by moving the pointer on the scale.
AUTHOR Elevation ASL 2025

The recommended size and stature are just indicative. It is recommended to always consult your choice with the dealer.

  • S/T c-t - seat tube (center-top), length of the seat tube from the middle of BB parts to its peak
  • S/T c-c - seat tube (center-center), length of the seat tube from the middle of BB parts to an axle of the upper tube
  • T/T h - top tube horizontal, horizontal lenght of the upper tube
  • T/T a - top tube actual, real lenght of the upper tube
  • H/T - head tube, head tube lenght
  • C/S - chain stay, chain brace lenght
  • W/B - wheel base, wheelbase (front and rear axle lenght)
  • S/T ang. - seat tube angel, angle between the seat tube axis and an imaginary line connecting the axes of the front and rear wheel
  • H/T ang. - head tube angel, angle between the head tube axis and an imaginary line connecting axes of the front and rear wheels
  • F/L - fork length, fork length from the head parts bottom to the middle of the front wheel
  • B/B drop - bottom bracked drop, lenght between an imaginary line connecting wheels centers and BB parts, measured from BB parts
  • F/R - fork rake, distances between the head tube axis and fork axis measured at center of the front wheel, so-called. off set

Product options

black / gold17" = UA#4296100223   19" = UA#4296100323
